455-00006 # IG60 Soros - vezeték nélküli IoT átjáró/WLAN WiFi 802.11ac/Bluetooth v5.0/ LTE / Ethernet port/ RS-232 port/RS-422/485 port/ USB port/ 9V ~ 30V/Sentrius™ IG60-SERIAL Gateway/ Linux /LAIRD
- 455-00006 # Soros - vezeték nélküli IoT átjáró/WLAN 802.11ac/Bluetooth v5.0/ LTE / Ethernet port/ RS-232 port/RS-422/485 port/ USB port/ 9V ~ 30V/Sentrius™ IG60-SERIAL Gateway/ Linux /LAIRD
- Best-in-Class Wireless Performance - 2x2 MIMO for more robust connections
- Multiple Ways to Connect - Wi-Fi, Bluetooth v5.0, Ethernet, Serial RS-232/422/485, USB
- Chain of Trust - signed and secured at every layer to protect your device
- Industry Leading Support - Global Tier 2 and FAE support for your application
- Laird Linux Version: A rugged, open environment for your application, provided with our Linux build, hardware root of trust, and development tools. Based on our powerful 60 Series SOM
-
Laird Connectivity’s Sentrius™ IG60-SERIAL, based on the Microchip SAMA5D36 processor, brings all of our industry competence and capabilities into one solution. Based on Laird's 60 Series SOM, send and receive device data via serial (RS232/422/485), with dual-Ethernet, USB, SD micro, Bluetooth, and 2x2 MIMO Wi-Fi.
We provide it in two variants:
Laird Linux Version: A rugged, open environment for your application, provided with our Linux build, hardware root of trust, and development tools. Based on our powerful 60 Series SOM.
AWS IoT Greengrass Version: Features our pre-configured AWS IoT Greengrass sandbox for your IoT applications! Enable just-in-time maintenance, capture sensor data and more for your legacy devices and Bluetooth sensors!
- Best-in-Class Wireless Performance - 2x2 MIMO for more robust connections
- Multiple Ways to Connect - Wi-Fi, Bluetooth, 5, Ethernet, Serial, USB
- Chain of Trust - signed and secured at every layer to protect your device
- Industry Leading Support - Global Tier 2 and FAE support for your application
The Internet of Things is at the edge of a new frontier, connecting the infrastructure of society to the Cloud, but realizing this dream comes with challenges. The real world is complicated, with thirty-year-old equipment that was born before the smart phone, wireless security threats and botnets. The Sentrius IG60 bridges wireless sensor data to the Cloud over an enterprise-grade Wi-Fi connection and can give new life to legacy wired equipment by adding security and wireless connectivity. Watch the video to learn more about this wireless IoT gateway.
Specifications
Chipset (MPU): Atmel/Microchip SAMA5D36 CortexChipset (Wireless): Marvell 88W8997/88PG823Wireless Specification: 802.11ac with 2x2 MU-MIMO, Bluetooth 5Certifications: FCC/IC/CE regulatory approvals (pending). CE, UL/IEC62368-1 hardware approvals (pending)Dimensions: 85 mm x 22 mm x 100 mmFlash Storage: 512 MB NAND FlashMemory: 256 MB LPDDR RAMMounting Style: DIN-rail or wall mountPhysical Interface: 2x Serial (RS232/422/485), 1x USB 2.0 Host, 1x MicroSD slot, 2x SMA antenna connectorSecurity: Chain of Trust - hardware root of trust tools. WEP/WPA/WPA2 wireless security.Temperature Range: -30° to +85° C (-22° to +185° F)Product Brief - IG60-BL654 and IG60-SERIAL All Brochure 03-27-20 Online Guide - IG60-SERIAL with AWS Greengrass All Documentation 03-19-20 Online Guide - IG60-SERIAL with Laird Linux All Documentation 03-19-20 EN/CE Certifications - IG60-SERIAL All Certification 02-17-20 FCC and IC Certifications - IG60-SERIAL All Certification 02-17-20 s!nus-elektrotechnikai bt.
