tM-AD8C # I/O Module/Modbus RTU/tiny/8AI/Single/Current, ICP DAS, ICP CON

The tM-AD8 is an current input module that includes 8 single-ended analog input channels and provides a programmable input range on all analog inputs (0 ~ 20 mA, 4 ~ 20 mA). The sampling rate of the tM-AD8 is adjustable and is available in either fast or normal mode and It also provides 4 KV ESD protection as well as 2500 Vrms intra-module isolation.

Industrial Automation Industrial Machinery Building Automation Food and Beverage Systems Semiconductor Fabrication Control Systems

Analog Input Input Channels 8 Single-ended Type 0 ~ 20 mA, 4 ~ 20 mA Resolution Normal Mode 14-bit Fast Mode 12-bit Sampling Rate Normal Mode 10 Hz total Fast Mode 200 Hz total Accuracy Normal Mode +/-0.1% Fast Mode +/-0.5% Zero Drift +/- 20 μV/°C Span Drift +/- 25 ppm/°C Input Impedance 125 Ω

Communication Interface RS-485 Format (N, 8, 1), (N, 8, 2), (O, 8, 1), (E, 8, 1) Baud Rate 1200 ~ 115200 bps Protocol DCON, Modbus/RTU, Modbus/ASCII Dual Watchdog Yes, Module (2.3 seconds), Communication (Programmable) LED Indicators Power 1 LED as Power Indicator Isolation Intra-module Isolation, Field-to-Logic 2500 VDC EMS Protection ESD (IEC 61000-4-2) ±4 kV Contact for Each Terminal ±8 kV Air for Random Point EFT (IEC 61000-4-4) +/-4kV for Power Power Requirements Reverse Polarity Protection Yes Powered from Terminal Block Yes, 10 ~ 30 VDC Consumption 0.7 W Max. Mechanical Dimensions (W x L x H) 52 mm x 98 mm x 27 mm Installation DIN-Rail Mounting Environment Operating Temperature -25 °C ~ +75 °C Storage Temperature -30 °C ~ +75 °C Humidity 10 ~ 95% RH, Non-condensing

tM-AD8C CR 8-channel Isolation Current Input Module (RoHS)
